Product Details:
Payment & Shipping Terms:
|
| Clear-Span Width: | 10m / 12m / 15m / 18m 10m / 15m / 20m / 25m / 30m |
Eave Height: | 4m |
|---|---|---|---|
| Ridge Height: | 4.68m / 5.01m / 5.49m / 5.99m 5.58m / 6.38m / 7.17m / 7.95m |
Roof Pitch: | 18º |
| Bay Distance: | 5m | Longest Component: | 5.45m / 6.5m / 8.05m / 9.65m 5.5m / 8.1m / 10.7m / 10.7m |
| Minimum Tent Length: | 10m | Maximum Tent Length: | No Limit |
| Roof Fixing: | Bar Tensioning | Main Profile: | 166 X 88 X 3mm (4-channel) 203 X 112 X 4mm(4-channel) 200 X 120 X 4 Mm(4-channel) 250 X 120 X 4mm(4-channel) |
| Max Allowed Windspeed: | 100km/hr 0.5kn/m2 | Eave Connection: | Hot-dip Galvanized Steel Insert |
| Framework Material: | Hard Pressed Extruded Aluminium 6061/T6(13HW) | Cover Material Wall Fabric: |
650g/Sqm White PVC 850g/Sqm White Or Coloured PVC 950g/Sqm Clear PVC |
| Printing: | Full Roof Digital Printing Available | Manufacturer's Warranty: | 10 Year Frame 3 Year White / Coloured PVC 2 Year Printed PVC / Clear PVC |
| Applications: | Wedding Coperrate Events Festivals Exhibitons Sporting Events Fairs And Markets |
||
| Highlight: | Versatile Heavy Duty frame Tent,Agricultural Storage Heavy Duty frame Tent,Versatile large heavy duty marquee |
||
The M Series Heavy Duty Marquee Tents are engineered to deliver exceptional strength, reliability, and flexibility for high-capacity events. Ideal for corporate galas, weddings, exhibitions, and festivals, these tents combine robust construction with sophisticated design to create elegant yet practical solutions for temporary or semi-permanent use.
| Profile Dimensions | Type |
|---|---|
| 166 x 88 x 3mm | 4-channel |
| 203 x 112 x 4mm | 4-channel |
| 200 x 120 x 4mm | 4-channel |
| 250 x 120 x 4mm | 4-channel |
The high-strength aluminum alloy frame is designed for maximum durability, allowing the M Series to withstand adverse weather conditions while maintaining safety and stability.
The M Series Heavy Duty Marquee Tents provide the ideal balance of performance, adaptability, and aesthetic appeal. With robust structural capabilities and an expansive, modular design, the M Series is the premier choice for organizations and individuals seeking reliable and sophisticated event tent solutions.
