Product Details:
Payment & Shipping Terms:
|
Clear-Span Width: | 8m | Eave Height: | 2.6m |
---|---|---|---|
Ridge Height: | 4.19m | Main Profile: | 100 X 48 X 3mm (4-channel) |
Max Allowed Windspeed: | 80km/hr 0.3kn/m2 | Eave Connection: | Hot-dip Galvanized Steel Insert |
Framework Material: | Hard Pressed Extruded Aluminium 6061/T6(13HW) | Cover Material Wall Fabric: |
650g/Sqm White PVC 850g/Sqm White PVC |
Manufacturer's Warranty: | 10 Year Frame 3 Year White PVC |
Applications: | Coperrate Events Festivals |
Highlight: | 8x15m Outdoor Party Marquee,Party Marquee Tent With Rain Gutters,8x15m marquee event tent |
The 8x15m Aluminum Clear Span A-Frame Tent is a premium outdoor shelter designed for versatility, durability, and customization. Constructed with a hard-pressed extruded aluminum 6061/T6 framework, the tent features a sturdy main profile of 100x48x3mm (4-channel) that can withstand winds up to 80km/hr (0.3kn/m²). Its roof and walls are made of high-quality white PVC fabric with 650g/sqm and 850g/sqm options, offering superior protection against UV rays, water penetration, and fire hazards.
The eave height of 2.6m and ridge height of 4.19m provide ample interior space for events, while the hot-dip galvanized steel insert ensures reliable eave connections. The Aluminum Clear Span A-Frame Tent Canopy (S Series) is engineered for versatility and adaptability, making it an exceptional choice for various events. The A Frame Marquee Tent combines practicality with a sleek, modern design to meet diverse event needs, from elegant weddings and vibrant parties to professional gatherings.
This tent is ideal for corporate events, festivals, and outdoor gatherings, with customization options such as full roof digital printing to match branding or thematic requirements. Backed by a manufacturer’s warranty of 10 years for the frame and 3 years for the PVC fabric, this marquee guarantees long-lasting performance.
Key Features
S2 / FD Series 100 x 48 | ||||
ITEM | SPECIFICATION | |||
Clear-Span Width | 8m | 9m | 10m | 12m |
Eave Height | 2.6m | |||
Ridge Height | 4.19m | 4.34m | 4.52m | 4.87m |
Roof Pitch | 20° | |||
Bay Distance | 3m | |||
Longest Component | 4.4m | 4.8m | 5.35m | 6.35m |
Minimum Tent Length | 6m | |||
Maxmimum Tent Length | No Limit | |||
Roof Fixing | Bar Tensioning | |||
Main Profile | 100 x 48 x 3mm (4-channel) | |||
Max Allowed Windspeed | 80km/hr 0.3kn/m² | |||
EaveConnection | Hot-dip galvanized steel insert | |||
Framework Material | Hard pressed extruded aluminium 6061/T6 (13HW) | |||
Cover Material Wall Fabric | 850gsm White or Coloured PVC 950gsm Clear PVC |
650gsm White PVC 850gsm Coloured PVC 950gsm Clear PVC |
||
Printing | Full Roof Digital Printing available | |||
Engineer Certification | Engineer Structural Certificate, Resistance of Fabrics to Water Penetration Test, Ultra Violet Protection Test, Fire Action Analysis | |||
Warranty | 10 Year Frame / 3 Year Fabric |
Why Choose the Top Tent A Frame Marquee Tent?
TopTent A-Frame Marquee Tents stand out due to their exceptional build quality, innovative design, and commitment to customer satisfaction. With certifications ensuring structural integrity, water resistance, UV protection, and fire safety, these tents deliver a reliable and safe solution for any event. The durable aluminum framework and premium PVC covers offer robust weather resistance, while customization options allow you to tailor the design to your specific needs. TopTent’s attention to detail, such as offering custom steel transport boxes for premium packaging, highlights their dedication to ensuring hassle-free logistics and long-term use.
