Product Details:
Payment & Shipping Terms:
|
| Clear-Span Width: | 14.9m | Eave Height: | 3m |
|---|---|---|---|
| Ridge Height: | 5.49m | Main Profile: | 166 X 88 X 3mm (4-channel) |
| Max Allowed Windspeed: | 90km/hr 0.3kn/m2 | Eave Connection: | Hot-dip Galvanized Steel Insert |
| Framework Material: | Hard Pressed Extruded Aluminium 6061/T6(13HW) | Cover Material Wall Fabric: |
650g/Sqm White PVC 850g/Sqm White PVC |
| Manufacturer's Warranty: | 10 Year Frame 3 Year White PVC |
Applications: | Festivals And Special Gatherings |
| Highlight: | 14.9x27m A Frame Marquee,Customized A Frame Marquee,14.9x27m event marquee tent |
||
![]()
TopTent’s 14.9x27m A-Frame Marquee Tent is the perfect choice for large-scale outdoor events such as festivals, corporate gatherings, and weddings. This customizable, premium marquee is designed to provide spacious, column-free interiors and elegant, refined aesthetics, ensuring your event stands out.
Key features include:
Key Features
| M1 / ED Series 166 x 88 | ||||
| ITEM | SPECIFICATION | |||
| Clear-Span Width | 10m | 12m | 15m | 18m |
| Eave Height | 3m | |||
| Ridge Height | 4.68m | 5.01m | 5.49m | 5.99m |
| Roof Pitch | 18° | |||
| Bay Distance | 5m | |||
| Longest Component | 5.45m | 6.5m | 8.05m | 9.65m |
| Minimum Tent Length | 10m | |||
| Maxmimum Tent Length | No Limit | |||
| Roof Fixing | Bar Tensioning | |||
| Main Profile | 166 x 88 x 3mm (4-channel) | |||
| Max Allowed Windspeed | 90km/hr 0.3kn/m² | |||
| EaveConnection | Hot-dip galvanized steel insert | |||
| Framework Material | Hard pressed extruded aluminium 6061/T6 (13HW) | |||
| Cover Material Wall Fabric | 850gsm White or Coloured PVC 950gsm Clear PVC |
650gsm White PVC 850gsm Coloured PVC 950gsm Clear PVC |
||
| Printing | Full Roof Digital Printing available | |||
| Engineer Certification | Engineer Structural Certificate, Resistance of Fabrics to Water Penetration Test, Ultra Violet Protection Test, Fire Action Analysis | |||
| Warranty | 10 Year Frame / 3 Year Fabric | |||
Why Choose TopTent A-Frame Marquee Tents?
With TopTent, you get reliable service, innovative design, and premium quality for your outdoor events, backed by our reputation for excellence.
![]()
